Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker
$222.99 $200.69
| Weight | 0.5 lbs |
|---|
7049 200 Amp Panel Mount 187 Series Circuit Breaker
Features:
- Combines switching and circuit protection into a single device*
- Clear, single lever operation
- “Trip Free” design cannot be held “ON” during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Large Clearance around terminal studs accecpt heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected – Safe for installation aboard gasoline powered boats
Specifications:
- Interrupt Rating – 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC
- Maximum Voltage Rating – 48 Volts DC
- Operating Temperature Range – -40xC to 85xC
- Circuit Breaker Type – Thermally responsive bi-metal blade
- Circuit Breaker Class – Type III – switchable/manual reset – trip free
- Terminal Stud Size – 5/16″-18
- Terminal Stud Torque – 75 in-lb
- Mounting Holes – Accept #10 (M5) Screw
- Weight Lb (Kg) – 0.50 (0.23)
- Case Material – Thermoset Polyester
