Name: Blue Sea 4304 WeatherDeck Water Resistant Fuse Panel - 4 Position - Grey
SKU: 4304
Price: 119.64 USD
Availability: InStock

WeatherDeck™ Water Resistant Fuse Panel

PN: 4304

Color: Gray

Features:

Panel front rated IP67 when properly mounted with watertight mounting gasket
IP67 – protected against immersion up to 1 meter for 30 minutes
Designed for flybridge and open cockpit applications
Independent label back lighting circuit for remote switching and dimming
Each panel can be mounted in four different orientations
Integrated ATO/ATC fuse based circuit protection
Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.

Specifications:

Weatherproof: Waterproof
Positions: 4
Nominal Voltage: 12v DC
Circuit Protection: Fuse
Maximum Amperage: 15A @ 12v DC (per circuit)
Panel Cumulative Rating: 60A
Backlit Label: Bicolored LED
Backlighting Amperage: 10mA/illuminated Circuit
Backlighting Voltage: 12v DC
Height: 4.3″
Width: 3.88″
Depth: 2.5″

Included:

(4) 4138 WeatherDeck® Toggle Switch Boot – Black
(4) 4150 WeatherDeck® Toggle Switch SPST – ON-OFF
(1) 4215 Waterproof DC Label Kit – 30 Black Square Labels V1
(4) 5242 ATO/ATC Fuse – 15 Amp
